Before Booster 4.15.0, we had been using Kotlin 1.3. The reason for sticking with such an old version was mainly Kotlin version compatibility. But supporting AGP 7.3 forced an upgrade, since AGP 7.3 itself depends on Kotlin 1.5. Consequently, Booster 4.15.0 took a long time to resolve compatibility issues.

Kotlin’s First-Class Citizen – Function

First-class functions (Function) are an essential feature of functional programming languages, and Kotlin is no exception. Because Function is so widely used in Kotlin, it is also a hotspot for compatibility issues. Have you ever wondered how Kotlin’s Function is implemented at the bytecode level? Take the following code as an example:

1
(Int) -> Int

To implement this in Java, you would need to define a Functional Interface:

1
2
3
4
@FunctionalInterface
interface Int2Int {
    int invoke(int value);
}

Or use the JDK’s built-in Function<T, R>:

1
Function<Int, Int> i2i = /* ... */;

Java 8’s standard API only provides Function<T, R> and BiFunction<T, U, R> for Function. To support more parameters, you either define a custom Functional Interface or use lambda expressions.

Kotlin has excellent built-in support for lambda expressions and defines Function0, Function1<P1, R>, … Function22<P1, …, P22, R> – a total of 23 Function interfaces in its standard library. Seeing this, you might wonder: what happens if a Function has more than 22 parameters? (I’ll leave that as a cliffhanger.)

Lambda vs Function Reference

Function Reference is a Kotlin concept; the equivalent in Java is Method Reference. They refer to the same thing – a reference to a method. For example:

1
Arrays.asList(args).forEach(System.out::println);

Here, System.out::println is a reference to the println method on the System.out instance. So what exactly is the difference from a lambda? That requires understanding how lambdas are represented at the bytecode level.

Lambda implementations generally fall into a few categories:

  1. Inner classes
  2. Method handles (MethodHandle)
  3. Dynamic proxies
  4. Other approaches

Each has its pros and cons. The compiler considers two main factors when choosing an implementation:

  1. Maximizing flexibility for future optimization without depending on a specific implementation
  2. Stability of the bytecode-level representation

Since lambda implementations generate anonymous methods, both Java and Kotlin support converting between lambdas and method references to avoid unnecessary anonymous methods. In other words, you can replace a lambda with a method reference:

  • Lambda form

    1
    2
    3
    listOf("a", "b").forEach {
        println(it)
    }

  • Method reference form

    1
    listOf("a", "b").forEach(::println)

Function Reference in Kotlin

In Kotlin, FunctionReference is primarily implemented via FunctionReferenceImpl at the bytecode level. Starting from Kotlin 1.7+, FunInterfaceConstructorReference was added. For example:

1
2
3
4
5
fun interface IFoo {
    fun foo()
}

val iFooCtor = ::IFoo

So whenever Kotlin code uses a method reference, FunctionReferenceImpl will appear in the compiled class file. Now, what does this have to do with compatibility?

The Downside of Kotlin 1.3 Function References

In Kotlin, we frequently write code like this:

1
2
3
4
5
6
7
8
9
fun func() {
    // ...
}

fun call(func: () -> Unit) {
    func()
}

call(::func)

Is there anything wrong with this?

On the surface it looks perfectly fine. But at the bytecode level, there are quite a few issues. The code above decompiles to roughly this Java equivalent:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
final class refs/LambdaKt$main$1 extends kotlin/jvm/internal/FunctionReference  implements kotlin/jvm/functions/Function0  {
    public synthetic bridge invoke()Ljava/lang/Object;

    public final invoke()V

    // overrides CallableReference#getOwner
    public final getOwner()Lkotlin/reflect/KDeclarationContainer;

    // overrides CallableReference#getName
    public final getName()Ljava/lang/String;

    // overrides CallableReference#getSignature
    public final getSignature()Ljava/lang/String;

    <init>()V

    public final static Lrefs/LambdaKt$main$1; INSTANCE

    static <clinit>()V
}

Can you spot the problem?

Kotlin 1.4 Callable Reference Optimization

From the decompiled code above, we can see that the Kotlin compiler generates many extra methods, most of which are rarely used. Why generate methods that are almost never called? Can we avoid generating them?

The answer is yes – and that is exactly the optimization Kotlin 1.4 introduced for FunctionReference, as shown below:

Kotlin 1.4 added AdaptedFunctionReference and introduced 2 new constructors in FunctionReferenceImpl:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
@SinceKotlin(version = "1.4")
public FunctionReferenceImpl(
    int arity,
    Class owner,
    String name,
    String signature,
    int flags
) {
    super(/* ... */);
}

@SinceKotlin(version = "1.4")
public FunctionReferenceImpl(
    int arity,
    Object receiver,
    Class owner,
    String name,
    String signature,
    int flags
) {
    super(/* ... */);
}

These parameters are then passed to the base class CallableReference through a new constructor in FunctionReference:

1
2
3
4
5
6
7
8
9
10
11
12
13
@SinceKotlin(version = "1.4")
public FunctionReference(
    int arity,
    Object receiver,
    Class owner,
    String name,
    String signature,
    int flags
) {
    super(receiver, owner, name, signature, (flags & 1) == 1);
    this.arity = arity;
    this.flags = flags >> 1;
}

And the corresponding fields, constructor, and getter methods were added to CallableReference:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
@SinceKotlin(version = "1.4")
private final Class owner;

@SinceKotlin(version = "1.4")
private final String name;

@SinceKotlin(version = "1.4")
private final String signature;

@SinceKotlin(version = "1.4")
private final boolean isTopLevel;

@SinceKotlin(version = "1.4")
protected CallableReference(Object receiver, Class owner, String name, String signature, boolean isTopLevel) {
    this.receiver = receiver;
    this.owner = owner;
    this.name = name;
    this.signature = signature;
    this.isTopLevel = isTopLevel;
}

So the methods that previously returned constants in anonymous inner classes are now passed to the base class via constructors, reducing the overall bytecode size of the application.

However, this optimization is enabled by default. This means the same Kotlin source code produces incompatible bytecode across versions – Kotlin 1.4+ compiled bytecode references FunctionReferenceImpl constructors that only exist in Kotlin 1.4+. This is the error you often encounter when upgrading Kotlin:

1
NoSuchMethodError: 'void kotlin.jvm.internal.FunctionReferenceImpl.<init>(int, java.lang.Class, java.lang.String, java.lang.String, int)'

This is particularly troublesome for Kotlin libraries. Take Booster for example: many projects still use older AGP versions, but Booster also needs to support the latest AGP, which requires Kotlin 1.5 as a minimum. This means Booster compiled with Kotlin 1.5 cannot run in projects using older AGP versions, unless they explicitly set the Kotlin version to 1.5 or above.

The Callable Reference Workaround

Engineers have likely encountered the problem above. By digging into the Kotlin source code, I found that this optimization can be disabled via a compiler option:

1
2
3
4
5
compileKotlin {
    kotlinOptions{
        freeCompilerArgs = ["-Xno-optimized-callable-references"]
    }
}

Or:

1
2
3
4
5
tasks.withType<KotlinCompile> {
    kotlinOptions {
        freeCompilerArgs = listOf("-Xno-optimized-callable-references")
    }
}

Does Kotlin have a systematic solution for this? Stay tuned for the next installment.
