In Designing Testable App Architecture (Part 1), we covered how Booster solves the problem of reusing Transformer across both local unit test and build environments. In this part, let’s explore how to use Booster‘s TransformerClassLoader to make app architectures testable.

Unit Testing Frameworks

In the Java world, the two most popular unit testing frameworks are JUnit and TestNG. Most developers have heard of JUnit but may not be familiar with TestNG. In my view, there isn’t much difference between them. Many developers are familiar with JUnit in theory but have rarely written real unit tests. Let’s start with a basic JUnit example:

1
2
3
4
5
6
7
8
public class Calculator {
  public int evaluate(String expression) {
    int sum = 0;
    for (String summand: expression.split("\\+"))
      sum += Integer.valueOf(summand);
    return sum;
  }
}
1
2
3
4
5
6
7
8
9
10
11
import static org.junit.Assert.assertEquals;
import org.junit.Test;

public class CalculatorTest {
  @Test
  public void evaluatesExpression() {
    Calculator calculator = new Calculator();
    int sum = calculator.evaluate("1+2+3");
    assertEquals(6, sum);
  }
}

Running evaluatesExpression in the IDE launches JUnit by default. If you need to mock classes, you’ll use a mocking framework like Mockito or PowerMock. When writing unit tests with these frameworks, you’ll inevitably encounter a JUnit component called Test Runner, typically specified via @RunWith on the test class:

MockitoJUnitRunner

1
2
3
4
@RunWith(MockitoJUnitRunner.class)
public class YourTestCase {
  ...
}

PowerMockRunner

1
2
3
4
@RunWith(PowerMockRunner.class)
public class YourTestCase {
  ...
}

For writing local unit tests for Java Library projects targeting the Android platform, Robolectric is commonly used. Like Mockito and PowerMock, it provides its own Test Runner – RobolectricTestRunner:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
@RunWith(RobolectricTestRunner.class)
public class WelcomeActivityTest {

  @Test
  public void clickingLogin_shouldStartLoginActivity() {
    WelcomeActivity activity = Robolectric.setupActivity(WelcomeActivity.class);
    activity.findViewById(R.id.login).performClick();

    Intent expectedIntent = new Intent(activity, LoginActivity.class);
    Intent actual = shadowOf(RuntimeEnvironment.application).getNextStartedActivity();
    assertEquals(expectedIntent.getComponent(), actual.getComponent());
  }

}

The Essence of Mocking

All mocking-capable frameworks inevitably rely on a Test Runner. Why?

To mock properties or methods in another class, you need to swap out the real ones. When does the swap happen, and how? There are generally two approaches – compile-time or runtime.

Compile-Time Injection

For regular Java projects, compile-time injection typically uses the Instrumentation mechanism available since Java 6. A Java Agent containing a ClassFileTransformer is provided to the JVM as a plugin via command-line arguments:

1
java -javaagent:my-agent.jar -jar my-app.jar

While this works, it requires developers to configure command-line arguments in the IDE’s run configuration, which isn’t a great developer experience.

Runtime Injection

Runtime injection typically uses a custom ClassLoader – like the TransformerClassLoader discussed earlier – to modify classes in memory during loading via a bytecode manipulation framework. Investigation shows that the mocking frameworks mentioned above all use runtime injection.

The Significance of Test Runner

JUnit provides the @RunWith annotation so developers can specify which Runner to use. JUnit also provides several built-in runners:

  • BlockJUnit4ClassRunner
  • BlockJUnit4ClassRunnerWithParameters
  • Suite
  • …

To implement runtime injection, we need a custom Runner. For convenience, we extend BlockJUnit4ClassRunner:

1
2
3
4
5
6
7
8
9
class BoosterTestRunner(clazz: Class<*>) : BlockJUnit4ClassRunner(clazz) {

  private val contextClassLoader = Thread.currentThread().contextClassLoader as URLClassLoader

  private val transformerClassLoader = TransformerClassLoader(contextClassLoader) {
    AsmTransformer(it)
  }

}

How do we make BoosterTestRunner execute when a @Test-annotated method runs? Let’s look at how BlockJUnit4ClassRunner actually works:

Now we understand JUnitTestClassExecutor‘s runtime sequence. Since we want to do something before each @Test-annotated method executes, we need to override BlockJUnit4ClassRunner‘s methodBlock(FrameworkMethod) method, replacing the Method referenced by FrameworkMethod with a modified one.

Where does the modified Method come from?

From the modified Class, of course:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
override fun methodBlock(method: FrameworkMethod): Statement {
  return object : Statement() {
    override fun evaluate() {
      val testClass = transformerClassLoader.loadClass(testClass.javaClass.name)
      val testRunner = MethodRunner(testClass)
      val testMethod = testClass.getMethod(method.method.name)

      try {
        testRunner.methodBlock(FrameworkMethod(testMethod)).evaluate()
      } finally {
        Thread.currentThread().contextClassLoader = delegate
      }
    }
  }
}

private class MethodRunner(clazz: Class<*>): BlockJUnit4ClassRunner(clazz) {
  public override fun methodBlock(method: FrameworkMethod): Statement {
    return super.methodBlock(method)
  }
}

With BoosterTestRunner, the full sequence for running a unit test looks like this:
