In the booming era of mobile internet, many modern programming languages emerged. Write Once and Run Anywhere is no longer exclusive to Java. Yet before Android came along, developing GUI applications on embedded Linux wasn’t straightforward. Despite powerful frameworks like Qt and GTK, developing in C/C++ always means confronting memory management. While C++ has the powerful boost library (standardized in C++11) with smart pointers that handle memory well, GTK in C doesn’t have it so easy – especially for application developers. How to make memory management easier has been an enduring topic.

Imagine launching a GUI application: you enter the main screen, tap a button to open another screen, then close it to return. Simple steps, but implementing this in C raises several questions:

  1. Should UI widgets be created on the main thread or a worker thread?
  2. Should click event handlers execute on the main thread or a worker thread?
  3. Who owns the memory of UI widgets created in code? When is it freed?

Let’s first look at how Java Swing creates UI widgets:

1
2
3
4
5
6
7
8
9
10
11
12
import javax.swing.*;

public class HelloWorld {
  public static void main(String[] argv) {
    JLabel label = new JLabel("Hello, world!", JLabel.CENTER);
    JFrame frame = new JFrame("Hello");
    frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
    frame.getContentPane().add(label);
    frame.setSize(200, 150);
    frame.setVisible(true);
  }
}

As we can see, Swing applications can create UI widgets on the main thread. However, according to Swing’s Threading Policy in the Javadoc, it’s best to create UI widgets on the Event Dispatching Thread (EDT):

1
2
3
4
5
6
7
8
9
10
11
12
13
14
import javax.swing.*;

public class HelloWorld {
  public static void main(String[] argv) {
    SwingUtilities.invokeLater(() -> {
      JLabel label = new JLabel("Hello, world!", JLabel.CENTER);
      JFrame frame = new JFrame("Hello");
      frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
      frame.getContentPane().add(label);
      frame.setSize(200, 150);
      frame.setVisible(true);
    });
  }
}

Even so, Swing doesn’t strictly enforce that UI operations must happen on the EDT. Now compare with how Android creates UI widgets:

1
2
3
4
5
6
7
8
9
10
11
public class MainActivity extends Activity {

  @Override
  public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstance);
    TextView label = new TextView(this);
    label.setText("Hello, world!");
    setContentView(label);
  }

}

Although Android explicitly defines the UI lifecycle, it doesn’t actually enforce that UI widget creation must happen on the main thread – which is why AsyncLayoutInflater is possible. What Android does enforce is that UI operations must happen on the main thread; otherwise, a ViewRootImpl$CalledFromWrongThreadException is thrown. To avoid thread-safety issues, it’s best to create widgets on the UI thread. In fact, in most GUI systems the main thread is the UI thread – Android, Cocoa, SWT, Qt, GTK, etc. – with AWT and Swing being the exceptions.

Now for the second question – the threading of click event handlers. Aside from inherently single-threaded languages like JavaScript, most languages default to a multi-threaded environment. Event handling typically uses callbacks. In C, a callback is a function pointer. To handle a click event in a callback, you pass the clicked UI widget as a parameter:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
static void button_click_cb(
  GtkWidget* widget,
  gpointer data
) {
  ...
}

void main(int argc, char* argv[]) {
  GtkWidget* button;

  ...

  gtk_signal_connect(
    GTK_OBJECT(button),
    "clicked",
    GTK_SIGNAL_FUNC(button_click_cb),
    NULL
  );

  ...
}

As we know, the main function executes synchronously from top to bottom. Once main finishes, the program exits. Yet in practice, a GUI application keeps running after starting from the main thread. This means the main thread hasn’t exited – it’s “parked” somewhere. But if it’s parked, why doesn’t the UI freeze? It’s actually still quite smooth.

If the callback executes on the main thread, how does execution jump from where the main thread is “parked” to the callback function? If the callback blocks or deadlocks, wouldn’t the entire GUI system become unresponsive? Would you have to restart the system? And if you want to avoid restarting, how do you solve this?

If the callback executes on a worker thread, there are thread-safety issues: the clicked widget was created on the main thread, so its memory is accessible from the main thread. How do you ensure thread safety? If every GUI widget access requires synchronization via locks, performance suffers dramatically. For developers, it’s hostile – locks everywhere, with deadlocks waiting to happen.

Many are familiar with the Event Loop. It’s widely used not just in GUI systems but also in non-GUI systems – Node.js uses it for asynchronous execution. This answers all the questions above:

  1. UI event callbacks execute on the main thread
  2. The main thread hasn’t exited because it’s “parked” in the Event Loop
  3. The Event Loop is driven by the main thread. It’s not truly frozen – it’s waiting for messages in a queue. Any thread can send messages to this queue, and the system itself has tasks that must run on the main thread (mouse movement, clicks, button presses, system events, etc.). These are sent as messages to the queue, waiting for the main thread to process them in subsequent loop iterations. One message per iteration – this elegantly solves the thread-safety problem.
  4. To prevent the main thread from getting stuck, the system runs a background process called a Watchdog that waits to be “fed.” If no one feeds it within a certain time, it “barks” – different systems handle this differently. Some display an App Not Responding (ANR) dialog letting the user choose to wait or kill the unresponsive process. Some kill the process without asking. For systems that require no human intervention or run critical tasks – embedded systems like Linux, VxWorks, RT-Thread – if the watchdog isn’t fed in time, the system reboots automatically.

So must all UI operations happen on the UI thread? Not necessarily. In GUI systems, most UI widgets are operated by the UI thread, meaning CPU-rendered. But animations and video demand extremely high frame rates. To achieve 60 FPS (Frames Per Second) silky smoothness, the CPU alone is far from sufficient – GPU acceleration is needed. This requires the GUI system’s view hierarchy to provide extension points for GPU rendering. For example, TextureView in Android and CALayer in iOS. Texture (AsyncDisplayKit) leverages CALayer to render on non-UI threads for a smoother user experience.

Finally, the third question – memory ownership of UI widgets. For runtimes without Garbage Collection (GC), memory management typically uses Reference Counting. This splits into Automatic Reference Counting (ARC) and Manual Reference Counting (MRC). GTK‘s memory management is classic MRC. Cocoa‘s is classic ARC. Cocoa achieves ARC through the combined work of the Clang compiler and the Objective-C runtime – Clang can analyze memory ownership at compile time and insert runtime-provided memory deallocation calls at the right places, sparing developers from manual memory management. For GUI systems using ARC or GC, the runtime controls memory ownership. For MRC-based GUI systems, the system itself handles memory management at appropriate times to avoid leaks. While developers rarely need to worry about UI widget memory in most cases, there are scenarios requiring manual reference counting.

Among popular compiled languages today, aside from Objective-C and Swift still using ARC, nearly all have implemented Garbage Collection. So is GC better than ARC? It depends on the perspective:

  1. From the developer’s perspective, GC is friendlier – you almost never worry about memory leaks
  2. From the end user’s perspective, GC-induced brief stutters do affect the experience

Despite Java being around for over 20 years since 1995, Sun, Oracle, and the Java community have never stopped optimizing the GC. This is one reason Huawei developed the Ark Compiler, whose goal includes solving GC-induced stutters. Moving away from GC toward “primarily ARC, supplemented by GC“ is the Ark Compiler’s main technical direction. Its ARC approach follows the same idea as the Clang compiler mentioned earlier – leveraging the compiler’s static analysis to automatically insert memory deallocation calls at compile time.
