I’ve been spending a lot of time lately optimizing booster-task-analyser – both refining features and improving performance. Previously, static analysis was handled by booster-transform-lint. Although that module was open-sourced early on, I was never satisfied with the analysis results. Factoring in other concerns, I decided to rewrite it from scratch – hence booster-task-analyser, designed to replace booster-transform-lint.

The redesign was driven by several considerations:

  1. Static analysis isn’t run as frequently as builds, so a Task is a better fit than a Transformer;
  2. CHA (Class Hierarchy Analysis) requires all class information upfront, while a Transformer processes classes in a pipeline – not ideal;
  3. Static analysis can be slow; as a Transformer, it would severely impact build performance, and the build doesn’t depend on analysis output anyway;

So booster-task-analyser is built as a Task:

digraph analyser { node [shape=rect,fillcolor="#41BBD9",style=filled,fontcolor=white,fontname=Helvetica]; analyse [color="#33330000",fillcolor="#F18F01"]; analyseDebug [color="#33330000",fillcolor="#006E90"]; analyseRelease [color="#33330000",fillcolor="#006E90"]; transformClassesWithXxxForDebug [color="#33330000",fillcolor="#99C24D"] transformClassesWithXxxForRelease [color="#33330000",fillcolor="#99C24D"] analyse -> analyseDebug [color="#555555"]; analyse -> analyseRelease [color="#555555"]; analyseDebug -> transformClassesWithXxxForDebug [color="#555555"]; analyseRelease -> transformClassesWithXxxForRelease [color="#555555"]; }

Classpath

Before performing static analysis, we need all the classes to analyze. These come from two sources:

  • System classes

    The APIs provided by the Android SDK – specifically, ${ANDROID_HOME}/platforms/android-xx/android.jar. During the build, these can be obtained via BaseExtension.getBootClasspath().

  • APP classes

    App classes are trickier. There are two approaches:

    1. Analyze project dependencies to discover them;
    2. Obtain them through Transform;

    The current implementation uses option 2 – relying on Transform – mainly because it’s easier to implement. Taking a shortcut here :P

I expected loading all classes (parsing class files into ASM ClassNode objects) to be time-consuming, but nearly 100,000 classes loaded in about 15 seconds. Machine specs:

  • Processor: 2.5GHz Intel Core i7
  • Memory: 16GB 2400 MHz DDR4
  • Storage: SSD

Entry Point

Every static analysis needs entry points. For a regular program, it’s typically the main method. For Android apps, the entry points are Application, the four major components, XML layouts, and so on. The first task is finding them all.

The Four Major Components

Application and the four major components are declared in AndroidManifest.xml. The merged manifest can be obtained via mergedManifests.

Custom Views

The most direct way to find custom Views is to parse Layout XML files. These can be obtained through mergeRes, though they come as AAPT2 artifacts – flat files. This is why the booster-aapt2 module exists.

Through testing, I found that parsing flat files is actually slower than parsing raw XML source files. So the final implementation only parses the flat file header to locate the source file path.

Thread-Annotated Methods and Classes

Android provides Thread Annotations to help compilers and static analysis tools improve code checking accuracy. Any class or method annotated with Thread Annotations can be treated as a thread entry point.

Since popular application frameworks also have thread annotations, Analyser supports Event Bus as well – methods annotated with @Subscribe(threadMode = MAIN) are identified as main thread entry methods.

Reflection

In Android apps, reflection is sometimes used to break reference chains between Application and other classes – for hot-fix support or to keep the Main Dex from growing too large. See: Working as an Architect at DiDi (Part 1). How do we connect reflective calls to their actual target methods? Stack frame analysis. That’s a topic for another day.

Main Looper

In Android, the main thread’s Looper and Handler also qualify as Entry Points. Determining whether a Handler or Looper runs on the main thread is genuinely challenging. For example:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
public class HomeActivity extends Activit {

    private Handler mHandler = new Handler();

    public void onResume() {
        super.onResume();
        Helper.handleEvent(this.mHandler);
    }

}

public class Helper {

    public static void handleEvent(Handler handler) {
        // ...
        handler.post(() -> {
            // update UI
        })
    }

}

The Call Graph looks like this:

digraph analyser { graph [bgcolor="transparent",pad="0.555"]; node [shape=box,fillcolor="#7f41BBD9",style=filled,fontcolor=white,fontname=Helvetica];
"HomeActivity.onResume()" [color="#33330000",fillcolor="#F18F01"];
"Activity.onResume()" [color="#33666600",fillcolor="#006E90"];
"Helper.handleEvent(Handler)" [color="#33666600",fillcolor="#99C24D"];
"Handler.post(Runnable)" [color="#33666600",fillcolor="#B5248F"];

"HomeActivity.onResume()" -> "Activity.onResume()" [color="#555555"];
"HomeActivity.onResume()" -> "Helper.handleEvent(Handler)" [color="#555555"];
"Helper.handleEvent(Handler)" -> "Handler.post(Runnable)" [color="#555555"];

}

In this example, Helper.handleEvent(Handler) calls a Handler, but that Handler comes from another method. To trace the handler parameter back to its origin, we need to analyze the Call Graph in reverse:

  1. Find the calling node(s) above the current one;
  2. Locate the INVOKE instruction corresponding to that node;
  3. Walk back from the instruction’s stack frame to determine the source of handler;
  4. handler comes from a GETFIELD instruction – it’s a member of HomeActivity;
  5. Search all methods for SETFIELD instructions that assign to handler, ultimately determining it was initialized in the constructor;

This shows how critical the Call Graph is for static analysis. This example is relatively simple; if the Handler is passed as a parameter through multiple methods, the algorithmic complexity increases significantly.

ClassSet

ClassSet serves several purposes:

  1. Fast lookup of ClassNode by class name;
  2. Fast lookup of which classpath (directory/JAR) a class belongs to;

For performance and reusability, ClassSet is designed as follows:

Why does CompositeClassSet exist? Because when Analyser analyzes an application, it needs access to these ClassSets:

  1. A ClassSet containing only System classes

For quickly finding Application and the four major components.

  1. A ClassSet containing only App classes

For building the application’s Call Graph.

  1. A ClassSet containing all classes – the union of System classes and App classes

For Class Hierarchy Analysis (CHA).

To ensure lookup efficiency, all ClassSet implementations use caching.

Class Hierarchy Analysis

Class hierarchy analysis is critical for static analysis – it determines both the accuracy and completeness of results. Previously, CHA was implemented using ClassLoader, which was relatively straightforward. See: KlassPool & Klass. The main goal was determining whether two types have an inheritance relationship. Why abandon the old approach and redesign CHA? Several reasons:

  1. When ClassLoader loads a Class, it verifies the bytecode even without initialization, potentially throwing VerifyError and failing the entire analysis;
  2. Performance – ClassLoader‘s class loading performance is far worse than ASM;
  3. Beyond inheritance, we also need to analyze fields, methods, and annotations – the information available through Class reflection is limited;

There’s another crucial requirement during class hierarchy analysis – polymorphism detection. For example:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
public interface ProfileView {
    void updateUserInfo(UserInfo userInfo);
}

public interface ProfilePresenter {
    void refreshUserInfo();
}

public class ProfilePresenterImpl implements ProfilePresenter {

    private ProfileView mView;

    private UserService mService;

    public ProfilePresenterImpl(ProfileView view) {
        this.mView = view;
    }

    public void refreshUserInfo() {
        this.mService.getUserInfo(userInfo -> {
            mView.updateUserInfo(userInfo);
        });
    }

}

public class ProfileActivity extends Activity, ProfileView {

    private ProfilePresenter mPresenter;

    public void onCreate(Bundle bundle) {
        super.onCreate(bundle);
        this.mPresenter = new ProfilePresenterImpl(this);
    }

    public void onResume() {
        super.onResume();
        this.mPresenter.refreshUserInfo();
    }

    public void updateUserInfo(UserInfo userInfo) {
        // ...
    }

}

If we represent ProfileActivity.onResume() as a Call Graph:

digraph analyser { graph [bgcolor="transparent",pad="0.555"]; node [shape=box,fillcolor="#7f41BBD9",style=filled,fontcolor=white,fontname=Helvetica];
"ProfileActivity.onResume()" [color="#33330000",fillcolor="#F18F01"];
"Activity.onResume()" [color="#33666600",fillcolor="#006E90"];
"ProfilePresenter.refreshUserInfo()" [color="#33666600",fillcolor="#99C24D"];
"ProfilePresenterImpl.refreshUserInfo()" [color="#33666600",fillcolor="#CCCCCC",fontcolor="#999999"];
"UserService.getUerInfo(Callback)" [color="#33666600",fillcolor="#CCCCCC",fontcolor="#999999"];

"ProfileActivity.onResume()" -> "Activity.onResume()" [color="#555555"];
"ProfileActivity.onResume()" -> "ProfilePresenter.refreshUserInfo()" [color="#555555"];
"ProfilePresenter.refreshUserInfo()" -> "ProfilePresenterImpl.refreshUserInfo()" [color="#555555",style="dotted"];
"ProfilePresenterImpl.refreshUserInfo()" -> "UserService.getUerInfo(Callback)" [color="#555555"];

}

Here’s the problem: in the Call Graph above, ProfileActivity.onResume() cannot reach ProfilePresenterImpl.updateUserInfo(), because the reference type calling updateUserInfo() in ProfileActivity is ProfilePresenter, not ProfilePresenterImpl. Each node in the Call Graph needs an attribute indicating whether it’s a virtual method. If it is, the virtual method must be linked to all override methods in derived classes. This gives rise to several requirements:

  1. Fast lookup of derived classes by class name;
  2. Fast lookup of subclasses that override a specific method, given a class name and method name;

Summary

As the examples above illustrate, static analysis involves quite complex data structures and algorithms, including:

  1. Link List
  2. Map
  3. Set
  4. Digraph
  5. Binary Tree
  6. ……

At sufficient scale, performance becomes a major challenge – a single line of code can make a dramatic difference.

When the first version of Analyser was completed, analyzing 100,000 classes took over half an hour. After continuous optimization, it now consistently finishes in about 1 minute with peak memory around 3GB. The optimization techniques involved are yet another topic for another day.
