How to Share Data Between Fragments?

In day-to-day feature development, we often encounter the need to share data between Fragments – for example, passing data from Fragment A to Fragment B. What approaches can achieve this?

The Naive Approach

The first thing that comes to mind is adding a field to the Activity:

MainActivity.kt

class MainActivity : FragmentActivity() {

    var sharedData: SharedData? = null

}

This way, Fragments can access the shared data through MainActivity:

Fragment1.kt

In Fragment1, fetch data from the API, then update it in MainActivity:

class Fragment1 : Fragment() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        val activity = (requireActivity() as? MainActivity)
        // ...
        findViewById(R.id.button).onClickListener {
            fetchSharedData() {
                activity?.sharedData = it
            }
        }
    }

}

Fragment2.kt

When Fragment2 is created, retrieve the shared data from MainActivity and update the UI:

class Fragment2 : Fragment() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        // ...
        val sharedData = (requireActivity() as? MainActivity)?.sharedData
        updateUI(sharedData)
    }

}

This does solve the data sharing problem, but can you spot the drawbacks?

1. SharedData is actually maintained by Fragment1. Putting it in MainActivity makes the ownership of SharedData unclear.

2. If other data needs to be shared between different Fragments, piling everything into MainActivity adds unnecessary burden and is outside MainActivity‘s responsibility.

3. If Fragment1 is used not only in MainActivity but also in other Activitys, how do you ensure Fragment1 can be reused across different Activitys without extra maintenance cost?

The Elegant Approach

The drawbacks of the previous approach boil down to two issues:

1. Responsibility
2. Scalability

The ideal solution should satisfy:

1. SharedData should only be maintained by Fragment1
2. MainActivity should not need any modifications

If we meet these conditions, Fragment1 would look like this:

class Fragment1 : Fragment() {

    var sharedData: SharedData? = null

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        // ...
        findViewById(R.id.button).onClickListener {
            fetchSharedData() {
                sharedData = it
            }
        }
    }

}

But this raises a few questions:

1. How can Fragment2 conveniently get a reference to SharedData from Fragment1?
2. If Fragment1 is destroyed, SharedData goes with it. How do we bind SharedData‘s lifecycle to MainActivity?

To address these questions, we can use the following approach:

LifecycleScope.kt

object LifecycleScope : LifecycleObserver {

    internal val shared: MutableMap<LifecycleOwner, MutableMap<Any, Any>> = mutableMapOf()

    @OnLifecycleEvent(Lifecycle.Event.ON_DESTROY)
    fun onDestroy(source: LifecycleOwner) {
        source.lifecycle.removeObserver(this)
        shared.remove(source)
    }

}

fun <K : Any, V : Any> LifecycleOwner.getShared(key: K): V? {
    return LifecycleScope.shared[this]?.get(key) as? V
}

fun <K : Any, V : Any> LifecycleOwner.putShared(key: K, value: V) {
    LifecycleScope.shared.getOrPut(this) {
        lifecycle.addObserver(LifecycleScope)
        mutableMapOf()
    }[key] = value
}

Fragment1.kt

class Fragment1 : Fragment() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        // ...
        findViewById(R.id.button).onClickListener {
            fetchSharedData() {
                requireActivity().putShared(SharedData::class.java, it)
            }
        }
    }

}

Fragment2.kt

class Fragment2 : Fragment() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        // ...
        val sharedData: SharedData? = requireActivity().getShared(SharedData::class.java)
        updateUI(sharedData)
    }

}

This way, MainActivity doesn’t need any modifications, the Activity doesn’t care about sharing behavior between Fragments, Fragments become more cohesive, and they can be reused in other Activitys at zero cost.

The Perfect Approach

The elegant approach works, but it requires an extra LifecycleScope class, and LifecycleScope is a singleton. While it won’t cause performance issues, it still feels less than perfect. Is there a better solution?

In fact, Android already provides one out of the box – ViewModel. Here’s what the implementation looks like using ViewModel:

SharedViewModel.kt

class SharedViewModel : ViewModel() {
}

Fragment1.kt

class Fragment1 : Fragment() {

    private val sharedViewModel: SharedViewModel by activityViewModels()

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        // ...
        findViewById(R.id.button).onClickListener {
            fetchSharedData() {
                sharedViewModel.sharedData = it
            }
        }
    }

}

Fragment2.kt

class Fragment2 : Fragment() {

    private val sharedViewModel: SharedViewModel by activityViewModels()

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        // ...
        updateUI(sharedViewModel.sharedData)
    }

}

Normally, when using ViewModel in a Fragment, you call the viewModels() extension function and create a ViewModel delegate via by. This delegate is bound to the Fragment‘s lifecycle. To keep the shared data available even after a Fragment is destroyed, you use activityViewModels() instead, which binds the ViewModel delegate to the Activity‘s lifecycle.
